The EM LED Switching Power Supply is a 60W power supply designed to convert AC input into 12V DC output for compatible LED lighting applications.
Featuring a slim metal housing with a ribbed exterior, the unit is equipped with screw terminal connections for electrical wiring. It also includes a three-position DIP switch with percentage-based adjustment settings printed on the product label.
Suitable for compatible 12V DC LED lighting installations requiring a power supply rated up to 60W.
60W Rated Power: Delivers 12V DC output with a maximum current of 5A.
AC to DC Conversion: Accepts 175–265V AC input at 50/60Hz.
Slim Metal Housing: Ribbed metal exterior with mounting slots.
Screw Terminal Connections: Separate terminals for AC input and DC output.
DIP Switch Adjustment: Three-position switch with percentage settings indicated on the label.
Compact Linear Design: Narrow housing suitable for installations with compatible mounting space.
| Product Type | LED Switching Power Supply |
|---|---|
| Brand / Marking | EM |
| Model | WM-60-12-CC-XW |
| Rated Power | 60W |
| Input Voltage | 175–265V AC |
| Input Frequency | 50/60Hz |
| Output Voltage | 12V DC |
| Maximum Output Current | 5.0A |
| Housing | Metal |
| Connection Type | Screw Terminals |
| Adjustment | 3-Position DIP Switch |
